ANSON 安頌PVF-40/30-70/55/35-10 10S PVF-30-35-10 臺灣葉片泵

ANSON 安頌PVF-40/30-70/55/35-10 10S PVF-30-35-10 臺灣葉片泵

液壓系統中電磁閥的安裝使用和故障排除

給大家總結下 液壓系統中電磁閥的安裝使用和故障排除，一起來看看。
一、液壓電磁閥的安裝使用：
1、安裝前應參閱該産品的使用說明書，是否符合您的使用要求。
2、管路使用之前應沖洗干淨，介質不清潔的應安裝過濾器，以防止雜質妨礙液壓電磁閥的正常工作。
3、液壓電磁閥一般是單向工作的，不能反裝，閥上箭頭是管路流體的運動方向，必須保持一緻。
4、液壓電磁閥安裝一般閥體水平，線圈垂直向上，有部分産品可以任意安裝，但在條件允許時最好垂直，以增長使用壽命。
5、液壓電磁閥在結冰場所重新工作時應加熱處理，或設置保溫措施。
6、電磁線圈引出線(接插件)連接好后，應確認是否牢固，聯接電器元件觸點不應抖動，松動將引起液壓電磁閥不工作。
7、連續要生産工作的液壓電磁閥，最好采用旁路，便于檢修，不影響生産。
8、長時間停用后的液壓電磁閥，應排清凝結物后方可使用;拆洗時各零件要按順序放好再恢複原狀裝好。

二、液壓電磁閥的故障與排除：
(一)液壓電磁閥通電后不工作：
1、檢查電源接線是否不良——)重新接線和接插件的連接;
2、檢查電源電壓是否在±工作范圍——)調至正常位置范圍;
3、結圈是否脫焊——)重新焊接;
4、線圈短路——)更換線圈;
5、工作壓差是否不合適——)調整壓差——)或更換相稱的液壓電磁閥;
6、流體溫度過高——)更換相稱的液壓電磁閥;
7、有雜質使液壓電磁閥的主閥芯和動鐵芯卡死——)進行清洗，如有密封件損壞應更換密封件并安裝過濾器;
8、液體粘度太大，頻率太高和壽命已以——)更換産品。
(二)液壓電磁閥不能關閉：
1、主閥芯或鐵動芯的密封件已損壞——)更換密封件;
2、流體溫度、粘度是否過高——)更換對口的液壓電磁閥;
3、有雜質進入液壓電磁閥閥芯或動鐵芯——)進行清洗;
4、彈簧壽命已到或變形——)更換彈簧;
5、節流孔平衡孔堵塞——)及時清洗;
6、工作頻率太高或壽命已到——)改選産品或更換産品。
(三)其它情況：
1、內洩漏——)檢查密封件是否損壞，彈簧是否裝配不良;
2、外洩漏——)連接處松動或密封件已壞——)緊螺絲或更換密封件;
3、通電時有噪聲——)頭子上緊固件松動，擰緊。電壓波動不在允許范圍內，調整好電壓。鐵芯吸合面有雜質或不平，及時清洗或更換。

安頌

臺灣ANSON安頌VP5F-A3-50 PVF-30-35-10S VP5FD-A3-A2-50
臺灣安頌ANSON液壓油泵既有效率，高壓下穩定旋轉，反應靈敏，精度高，流量穩定，可以減少馬力的流失等等特點。葉片泵多式多樣，有單聯泵，雙聯泵，單聯和雙聯的又分開加長和標準的。油泵用到整機上后，噪音不大，可以達到比較理想的寧靜的工作環境。
1、變量葉片泵PVF高效率，高壓下穩定旋轉。特殊壓力控制機構，凸輪環3點支撐方式，使在大幅提高時的旋轉性能，在140bar下亦可發揮高效率，穩定的性能。
2、變量葉片泵PVF高效率，高壓下穩定旋轉。采用數種隔音，防振的新機構，尤其可提高凸輪環旋轉的穩定性。由控制活塞，偏位活塞所形成的特殊3點支撐方式，減少凸輪環振動，旋轉時務噪音。
3、變量葉片泵PVF反應靈敏，精度夠。嶄新的凸輪環控制機構，凸輪環無過位移，而提高反應靈敏度。啟動，停止，負荷變動時不會改變精密度。
4、變量葉片泵PVF靈敏的特性，流量穩定。嶄新的壓力平衡式壓力控制機構，在高壓狀態下流量亦高度的穩定順暢。
5、變量葉片泵PVF高效率旋轉，減少馬力損失。采用新機構減少損失馬力，尤其是高壓無輸出狀態時，更明顯的減少馬力損失。
6、變量葉片泵PVF維護，檢修容易。壓力調整裝置和流量調整裝置放在同一側面，方便維護，調整。

VP5F系列
VP5F-A2-50 VP5F-A2-50S VP5F-A3-50 VP5F-A3-50S VP5F-A4-50 VP5F-A4-50S VP5F-A5-50
VP5F-A5-50S VP5F-B2-50 VP5F-B2-50S VP5F-B3-50 VP5F-B3-50S VP5F-B4-50 VP5F-B4-50S
VP5F-B5-50 VP5F-B5-50S

VP5FD系列
VP5FD-A2-A2-50 VP5FD-A3-A2-50 VP5FD-A4-A2-50 VP5FD-A5-A2-50 VP5FD-A2-A3-50 VP5FD-A3-A3-50
VP5FD-A4-A3-50 VP5FD-A5-A3-50 VP5FD-A2-A4-50 VP5FD-A3-A4-50 VP5FD-A4-A4-50 VP5FD-A5-A4-50
VP5FD-A2-A5-50 VP5FD-A3-A5-50 VP5FD-A4-A5-50 VP5FD-A5-A5-50 VP5FD-B2-B2-50 VP5FD-B3-B2-50
VP5FD-B4-B2-50 VP5FD-B5-B2-50 VP5FD-B2-B3-50 VP5FD-B3-B3-50 VP5FD-B4-B3-50 VP5FD-B5-B3-50
VP5FD-B2-B4-50 VP5FD-B3-B4-50 VP5FD-B4-B4-50 VP5FD-B5-B4-50 VP5FD-B2-B5-50 VP5FD-B3-B5-50
VP5FD-B4-B5-50 VP5FD-B5-B5-50 VP5FD-A2-B2-50 VP5FD-A3-B2-50 VP5FD-A4-B2-50 VP5FD-A5-B2-50
VP5FD-A2-B3-50 VP5FD-A3-B3-50   VP5FD-A4-B3-50 VP5FD-A5-B3-50 VP5FD-A2-B4-50 VP5FD-A3-B4-50
VP5FD-A4-B4-50 VP5FD-A5-B4-50 VP5FD-A2-B5-50 VP5FD-A3-B5-50 VP5FD-A4-B5-50 VP5FD-A5-B5-50
VP5FD-B2-A2-50 VP5FD-B3-A2-50 VP5FD-B4-A2-50 VP5FD-B5-A2-50 VP5FD-B2-A3-50 VP5FD-B3-A3-50
VP5FD-B4-A3-50 VP5FD-B5-A3-50 VP5FD-B2-A4-50 VP5FD-B3-A4-50 VP5FD-B4-A4-50 VP5FD-B5-A4-50
VP5FD-B2-A5-50 VP5FD-B3-A5-50 VP5FD-B4-A5-50 VP5FD-B5-A5-50

PVF系列
PVF-12-20-10 PVF-12-20-10S PVF-12-35-10 PVF-12-35-10S
PVF-12-55-10 PVF-12-55-10S PVF-12-70-10 PVF-12-70-10S
PVF-20-20-10 PVF-20-20-10S PVF-20-35-10 PVF-20-35-10S
PVF-20-55-10 PVF-20-55-10S PVF-20-70-10 PVF-20-70-10S
PVF-30-20-10 PVF-30-20-10S PVF-30-35-10 PVF-30-35-10S
PVF-30-55-10 PVF-30-55-10S PVF-30-70-10 PVF-30-70-10S
PVF-40-20-10 PVF-40-20-10S PVF-40-35-10 PVF-40-35-10S
PVF-40-55-10 PVF-40-55-10S PVF-40-70-10 PVF-40-70-10S

PVDF系列
PVDF-320-320-10 PVDF-320-320-10S PVDF-320-335-10 PVDF-320-335-10S PVDF-320-355-10
PVDF-320-355-10S PVDF-320-370-10 PVDF-320-370-10S PVDF-335-320-10 PVDF-335-320-10S
PVDF-335-335-10 PVDF-335-335-10S PVDF-335-355-10 PVDF-335-355-10S PVDF-335-370-10
PVDF-335-370-10S  PVDF-355-320-10 PVDF-355-320-10S PVDF-355-335-10 PVDF-355-335-10S
PVDF-355-355-10 PVDF-355-355-10S PVDF-355-370-10 PVDF-355-370-10S PVDF-370-320-10
PVDF-370-320-10S PVDF-370-335-10 PVDF-370-335-10S PVDF-370-355-10 PVDF-370-355-10S
PVDF-370-370-10 PVDF-370-370-10S PVDF-420-420-10 PVDF-420-420-10S PVDF-420-435-10
PVDF-420-435-10S PVDF-420-455-10 PVDF-420-455-10S PVDF-420-470-10 PVDF-420-470-10S
PVDF-435-420-10 PVDF-435-420-10S PVDF-435-435-10 PVDF-435-435-10S PVDF-435-455-10
PVDF-435-455-10S PVDF-435-470-10 PVDF-435-470-10S PVDF-455-420-10 PVDF-455-420-10S
PVDF-455-435-10 PVDF-455-435-10S PVDF-455-455-10 PVDF-455-455-10S PVDF-455-470-10
PVDF-455-470-10S PVDF-470-420-10 PVDF-470-420-10S PVDF-470-435-10 PVDF-470-435-10S
PVDF-470-455-10 PVDF-470-455-10S PVDF-470-470-10 PVDF-470-470-10S PVDF-320-420-10
PVDF-320-420-10S PVDF-320-435-10 PVDF-320-435-10S PVDF-320-455-10 PVDF-320-455-10S
PVDF-320-470-10 PVDF-320-470-10S PVDF-335-420-10 PVDF-335-420-10S PVDF-335-435-10
PVDF-335-435-10S PVDF-335-455-10 PVDF-335-455-10S PVDF-335-470-10 PVDF-335-470-10S
PVDF-355-420-10 PVDF-355-420-10S PVDF-355-435-10 PVDF-355-435-10S PVDF-355-455-10
PVDF-355-455-10S PVDF-355-470-10 PVDF-355-470-10S PVDF-370-420-10 PVDF-370-420-10S
PVDF-370-435-10 PVDF-370-435-10S PVDF-370-455-10 PVDF-370-455-10S PVDF-370-470-10
PVDF-370-470-10S PVDF-420-320-10 PVDF-420-320-10S PVDF-420-335-10 PVDF-420-335-10S
PVDF-420-355-10 PVDF-420-355-10S PVDF-420-370-10 PVDF-420-370-10S PVDF-435-320-10
PVDF-435-320-10S PVDF-435-335-10 PVDF-435-335-10S PVDF-435-355-10 PVDF-435-355-10S
PVDF-435-370-10 PVDF-435-370-10S PVDF-455-320-10 PVDF-455-320-10S PVDF-455-335-10
PVDF-455-335-10S PVDF-455-355-10 PVDF-455-355-10S PVDF-455-370-10 PVDF-455-370-10S
PVDF-470-320-10 PVDF-470-320-10S PVDF-470-335-10 PVDF-470-335-10S PVDF-470-355-10
PVDF-470-355-10S PVDF-470-370-10 PVDF-470-370-10S
臺灣ANSON安頌
IVP1-2/3/4/5/6/7/8/9/10/11/12/14-F-R-1A/B/C/D-10
IVP1-2-F-R IVP1-3-F-R IVP1-4-F-R  IVP1-5-F-R IVP1-6-F-R IVP1-7-F-R IVP1-8-F-R  IVP1-10-F-R
IVP1-11-F-R IVP1-12-F-R IVP1-14-F-R  IVP1-2-F-R-1A-10 IVP1-3-F-R-1A-10 IVP1-4-F-R-1A-10
IVP1-5-F-R-1A-10 IVP1-6-F-R-1A-10 IVP1-7-F-R-1A-10 IVP1-8-F-R-1A-10  IVP1-10-F-R-1A-10
IVP1-11-F-R-1A-10 IVP1-12-F-R-1A-10 IVP1-14-F-R-1A-10  IVP1-2-F-R-1B-10 IVP1-3-F-R-1B-10
IVP1-4-F-R-1B-10  IVP1-5-F-R-1B-10 IVP1-6-F-R-1B-10 IVP1-7-F-R-1B-10 IVP1-8-F-R-1B-10
IVP1-10-F-R-1B-10 IVP1-11-F-R-1B-10 IVP1-12-F-R-1B-10 IVP1-14-F-R-1B-10  IVP1-2-F-R-1C-10
IVP1-3-F-R-1C-10 IVP1-4-F-R-1C-10  IVP1-5-F-R-1C-10 IVP1-6-F-R-1C-10 IVP1-7-F-R-1C-10
IVP1-8-F-R-1C-10  IVP1-10-F-R-1C-10 IVP1-11-F-R-1C-10 IVP1-12-F-R-1C-10 IVP1-14-F-R-1C-10
IVP1-2-F-R-1D-10 IVP1-3-F-R-1D-10 IVP1-4-F-R-1D-10  IVP1-5-F-R-1D-10 IVP1-6-F-R-1D-10
IVP1-7-F-R-1D-10 IVP1-8-F-R-1D-10  IVP1-10-F-R-1D-10 IVP1-11-F-R-1D-10 IVP1-12-F-R-1D-10
IVP1-14-F-R-1D-10

臺灣ANSON安頌IVP2-10/12/14/15/17/19/21/25-F-R-A/B/C/D/-10
IVP2-10-F-R,IVP2-12-F-R,IVP2-14-F-R,IVP2-15-F-R,
IVP2-17-F-R,IVP2-19-F-R,IVP2-21-F-R,IVP2-25-F-R,
IVP2-10-F-R-1A-10,IVP2-12-F-R-1A-10,IVP2-14-F-R-1A-10,IVP2-15-F-R-1A-10,
IVP2-17-F-R-1A-10,IVP2-19-F-R-1A-10,IVP2-21-F-R-1A-10,IVP2-25-F-R-1A-10,
IVP2-10-F-R-1B-10,IVP2-12-F-R-1B-10,IVP2-14-F-R-1B-10,IVP2-15-F-R-1B-10,
IVP2-17-F-R-1B-10,IVP2-19-F-R-1B-10,IVP2-21-F-R-1B-10,IVP2-25-F-R-1B-10,
IVP2-10-F-R-1C-10,IVP2-12-F-R-1C-10,IVP2-14-F-R-1C-10,IVP2-15-F-R-1C-10,
IVP2-17-F-R-1C-10,IVP2-19-F-R-1C-10,IVP2-21-F-R-1C-10,IVP2-25-F-R-1C-10,
IVP2-10-F-R-1D-10,IVP2-12-F-R-1D-10,IVP2-14-F-R-1D-10,IVP2-15-F-R-1D-10,
IVP2-17-F-R-1D-10,IVP2-19-F-R-1D-10,IVP2-21-F-R-1D-10,IVP2-25-F-R-1D-10,

臺灣ANSON安頌IVP3-17/21/25/30/32/35/38/42-F-R-1A/B/C/D-10
IVP3-17-F-R,IVP3-21-F-R,IVP3-25-F-R,IVP3-30-F-R,
IVP3-32-F-R,IVP3-35-F-R,IVP3-38-F-R,IVP3-42-F-R,
IVP3-17-F-R-1A-10,IVP3-21-F-R-1A-10,IVP3-25-F-R-1A-10,IVP3-30-F-R-1A-10,
IVP3-32-F-R-1A-10,IVP3-35-F-R-1A-10,IVP3-38-F-R-1A-10,IVP3-42-F-R-1A-10,
IVP3-17-F-R-1B-10,IVP3-21-F-R-1B-10,IVP3-25-F-R-1B-10,IVP3-30-F-R-1B-10,
IVP3-32-F-R-1B-10,IVP3-35-F-R-1B-10,IVP3-38-F-R-1B-10,IVP3-42-F-R-1B-10,
IVP3-17-F-R-1C-10,IVP3-21-F-R-1C-10,IVP3-25-F-R-1C-10,IVP3-30-F-R-1C-10,
IVP3-32-F-R-1C-10,IVP3-35-F-R-1C-10,IVP3-38-F-R-1C-10,IVP3-42-F-R-1C-10,
IVP3-17-F-R-1D-10,IVP3-21-F-R-1D-10,IVP3-25-F-R-1D-10,IVP3-30-F-R-1D-10,
IVP3-32-F-R-1D-10,IVP3-35-F-R-1D-10,IVP3-38-F-R-1D-10,IVP3-42-F-R-1D-10,
VD系列
VD08-A-10 VD08-A-10S VD12-A-10 VD12-A-10S VD16-A-10
VD16-A-10S VD08-B-10 VD08-B-10S VD12-B-10 VD12-B-10S
VD16-B-10 VD16-B-10S VD08-C-10 VD08-C-10S VD12-C-10
VD12-C-10S VD16-C-10 VD16-C-10S VD08-D-10 VD08-D-10S
VD12-D-10 VD12-D-10S VD16-D-10 VD16-D-10S

SVD系列
SVD-08-A-10 SVD-08-A-10S SVD-08-B-10 SVD-08-B-10S SVD-08-C-10
SVD-08-C-10S SVD-08-D-10 SVD-08-D-10S SVD-12-A-10 SVD-12-A-10S
SVD-12-B-10 SVD-12-B-10S SVD-12-C-10 SVD-12-C-10S SVD-12-D-10
SVD-12-D-10S

TPF系列
TPF-VL301-GH1-10 TPF-VL301-GH1-10S TPF-VL301-GH2-10 TPF-VL301-GH2-10S PF-VL301-GH3-10
TPF-VL301-GH3-10S TPF-VL301-GH4-10 TPF-VL301-GH4-10S TPF-VL301-GH5-10 TPF-VL301-GH5-10S
TPF-VL301-GH6-10 TPF-VL301-GH6-10S TPF-VL301-GH7-10 TPF-VL301-GH7-10S TPF-VL301-GH8-10
TPF-VL301-GH8-10S TPF-VL301-GH9-10 TPF-VL301-GH9-10S TPF-VL301-G00-10 TPF-VL301-G00-10S
TPF-VL401-GH1-10 TPF-VL401-GH1-10S TPF-VL401-GH2-10 TPF-VL401-GH2-10S TPF-VL401-GH3-10
TPF-VL401-GH3-10S TPF-VL401-GH4-10 TPF-VL401-GH4-10 TPF-VL401-GH5-10 TPF-VL401-GH5-10S
TPF-VL401-GH6-10 TPF-VL401-GH6-10S TPF-VL401-GH7-10 TPF-VL401-GH7-10S TPF-VL401-GH8-10
TPF-VL401-GH8-10S TPF-VL401-GH9-10 TPF-VL401-GH9-10S TPF-VL401-G00-10 TPF-VL401-G00-10S
TPF-VL302-GH1-10 TPF-VL302-GH1-10S TPF-VL302-GH2-10 TPF-VL302-GH2-10S TPF-VL302-GH3-10
TPF-VL302-GH3-10S TPF-VL302-GH4-10 TPF-VL302-GH4-10S TPF-VL302-GH5-10 PF-VL302-GH5-10S
TPF-VL302-GH6-10 TPF-VL302-GH6-10S TPF-VL302-GH7-10 TPF-VL302-GH7-10S TPF-VL302-GH8-10
TPF-VL302-GH8-10S TPF-VL302-GH9-10 TPF-VL302-GH9-10S TPF-VL302-G00-10 TPF-VL302-G00-10S
TPF-VL402-GH1-10 TPF-VL402-GH1-10S TPF-VL402-GH2-10 TPF-VL402-GH2-10S TPF-VL402-GH3-10
TPF-VL402-GH3-10S TPF-VL402-GH4-10 TPF-VL402-GH4-10S TPF-VL402-GH5-10 TPF-VL402-GH5-10S
TPF-VL402-GH6-10 TPF-VL402-GH6-10S TPF-VL402-GH7-10 TPF-VL402-GH7-10S TPF-VL402-GH8-10
TPF-VL402-GH8-10S TPF-VL402-GH9-10 TPF-VL402-GH9-10S TPF-VL402-G00-10 TPF-VL402-G00-10S
